Realize More Possibilities with Omada
JetStream 24-Port 10/100Mbps + 4-Port Gigabit Smart PoE+ Switch
Centralized Cloud Management
Omada SDN Platform Integration
Advanced L2+ Features
L2/L3/L4 QoS, ACL, Static Routing and More
Abundant Security Strategies
LAN Area Investment Protection
PoE+ Output
24 PoE+ Ports with Total 250 W Power Budget
Dedicated 24 PoE+ Ports (250 W Budget) for Numerous Applications
Compliance with the 802.3af/at PoE+ standard supports up to 30 W on each PoE port. The total 250 W PoE power budget* for the 24× 10/100Mbps PoE+ ports makes it has a wide range of applications, such as surveillance, offices, dormitories, and small businesses. It is fully compatible with IP cameras, access points, IP phones, computers, printers, etc.
Software Defined Networking (SDN) with Cloud Access
Omada's Software Defined Networking (SDN) platform integrates network devices, including access points, switches and gateways, providing 100% centralized cloud management. Omada creates a highly scalable network-all controlled from a single interface. Seamless wireless and wired connections are provided, ideal for use in hospitality, education, retail, offices, and more.
- Hassle-Free Cloud or On-Premises Controllers
- Multi-Site Cloud Management
- Zero-Touch Provisioning (ZTP)**
- Intelligent Monitoring
- General Information
- Manufacturer
- TP-LINK Technologies Co., Ltd
- Manufacturer Website Address
- http://www.tp-link.com/us
- Brand Name
- TP-Link
- Product Line
- JetStream
- Product Type
- Ethernet Switch
- Interfaces/Ports
- Total Number of Network Ports
- 24
- Uplink Port
- Yes
- Network (RJ-45)
- Yes
- Port/Expansion Slot Details
- 24 x 10/100 Mbps RJ-45 PoE+ Network Port
- 2 x 10/100/1000 Mbps RJ-45 Port
- 2 x Gigabit SFP Expansion Slot
- Media & Performance
- Media Type Supported
- Twisted Pair
- Optical Fiber
- Ethernet Technology
- Gigabit Ethernet
- Network Technology
- 1000Base-X
- 10/100/1000Base-T
- Maximum Data Transfer Rate
- 125 MB/s
- I/O Expansions
- Number of Total Expansion Slots
- 2
- Expansion Slot Type
- SFP
- Number of SFP Slots
- 2
- Network & Communication
- Layer Supported
- 2
- Networking Standards
- IEEE 802.3i
- IEEE 802.3u
- IEEE 802.3ab
- IEEE 802.3z
- IEEE 802.3ad
- IEEE 802.3x
- IEEE 802.3az
- IEEE 802.1D
- IEEE 802.1s
- IEEE 802.1w
- IEEE 802.1Q
- IEEE 802.1x
- IEEE 802.1p
- IEEE 802.3af
- IEEE 802.3at
- Management & Protocols
- Manageable
- Yes
- Power Description
- PoE (RJ-45) Port
- Yes
- PoE Budget
- 250 W
- Power Consumption
- 286.70 W
- Physical Characteristics
- Compatible Rack Unit
- 1U
- Form Factor
- Rack-mountable
- Height
- 1.7"
- Width
- 17.3"
- Depth
- 7.1"
- Miscellaneous
- Application/Usage
- Surveillance
- Office
- Dormitory
- Business
- IP Camera
- IP Phone
- Printer
- Education
- Retail
